Log graph

This example demonstrates how to use a custom tick formatter to display a log axis.

 pragma ComponentBehavior: Bound
 // SPDX-FileCopyrightText: Copyright (c) 2024 Refeyn Ltd and other QuickGraphLib contributors
 // SPDX-License-Identifier: MIT

 import QtQuick
 import QuickGraphLib as QuickGraphLib
 import QuickGraphLib.GraphItems as QGLGraphItems
 import QuickGraphLib.PreFabs as QGLPreFabs

 QGLPreFabs.XYAxes {
     id: root

     grid.strokeColor: "#20000000"
     grid.xTicks: QuickGraphLib.Helpers.linspace(-1, 1, 3)
     viewRect: Qt.rect(-1.6, -5.1, 3.2, 10.2)
     xAxis.decimalPoints: 0
     xLabel: "x"
     yAxis.decimalPoints: 0
     yLabel: "tan(x)"

     xAxis.tickDelegate: QuickGraphLib.TickLabel {
         color: root.xAxis.tickLabelColor
         decimalPoints: root.xAxis.decimalPoints
         direction: root.xAxis.direction
         font: root.xAxis.tickLabelFont
         text: "10<sup>%1</sup>".arg(Number(value).toFixed(decimalPoints))
         textFormat: Text.RichText
     }

     QGLGraphItems.Grid {
         // Minor grid ticks
         dataTransform: root.dataTransform
         strokeColor: "#09000000"
         strokeWidth: 1
         viewRect: root.viewRect
         xTicks: QuickGraphLib.Helpers.logspace(-2, 2, 5).slice(0, -1).map(x => QuickGraphLib.Helpers.linspace(x, x * 10, 11).slice(0, -1).map(xminor => Math.log10(xminor))).reduce((a, b) => a.concat(b), [])
         yTicks: root.grid.yTicks
     }
     QGLGraphItems.Line {
         dataTransform: root.dataTransform
         path: QuickGraphLib.Helpers.logspace(-1.5, 1.5, 1000).map(x => Qt.point(Math.log10(x), Math.tan(x)))
         strokeColor: "red"
     }
 }
